Media Water
Material Brass/Bronze
Brand FLUIDTECQ
Pressure 0.5 bar to 9 bar
Size 1/2″ to 2″
Type Diaphragm type
Actuation Type Direct cum pilot
Connection Type Screwed
Media Type Water, Gas, Oil
Type Of Coil Protection IP67
Temperature Of Media Medium Temperature
Coil Voltage 110V, 220V, 12V, 24V

The resilience of Diaphragm allows it to seal around particulates in the fluid, making it ideal for service with slurries, Air, Water, Oil. Diaphragm solenoid valves are used wherever fluid flow has to be controlled automatically. They are being used to an increasing degree in the most varied types of plants and equipment. 100% factory tested to ensure zero leakage from valves. Coils are made inhouse. Pick-up and drop-out as per standard. FLAMEPROOF diaphragm valves available.

Features:

Type: 2/2 Way Pilot Operated Diaphragm Valve.
Media: Dry or Lubricated Air / Inhert Gases / Water / Oil.
Nominal Diameter: 8 to 50 mm.
Material of construction: Aluminium / Brass / Steel(Optional).
Internals: SS / Brass.

Technical Specifications:

Port Sizes: 1/4″ bsp to 2″ bsp.
Max Pressure: 40 kg/cm2
Pressure ratings: Operates at gravity pressure to 10 bar – standard version
Coil Insulation: Class F and Class H
Coil protection: IP68

Additional Information:

Item Code: FT-GA
Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),Other
Port of Dispatch: MUMBAI
Production Capacity: 750 PER MONTH
Delivery Time: WITHIN 1 WEEK
Packaging Details: CARDBOARD BOX

Fluidtecq Pneumatics Private Limited
