Features:
Choice of Tie Rod or C-Frame Construction.
With or without isolating valve.
Material integrity assured through strict compliance of chemical composition analysis in a Standard Laboratory.
H Grade Borosilicate glass tube 16/19/25 mm outer dia with Teflon Packing.
Glass tube an be removed online i.e. without disconnection from vessel
Standard Connection: 1/2″ / 3/4″ / 1″ Flange drilled to ASA 150#, others on request
Alluminium/SS scale with 5 mm resolution as standard and 1 mm on request.
Drain Plug 1/2″ Vent Plug 3/4″ as std and drain/vent valve as optional
Safety Ball check device(optional).
Defrost/illuminator available on request.
