Features

Spindle The spindle is supported by 4 pieces of class 7 (p4) super precision angular contact ball bearings and directly coupled with low vibration class v3 spindle motor. Air purged spindle available upon request.

Base and saddle Specially designed one-piece T-shaped base casting offers superior rigidity.Hand-scraped, Turcite-B Coated crossfeed guideways between base and saddle have double “V” design; provides support for full table travel and prevents table overhangs.

Hydraulic creep-feed function Table longitudinal movement speed can be adjusted easily by tuming these two knobs. (H type standard).

Quick lock/unlock mechanism Hydraulic cylinder can be disengaged very quickly for quick fixture alignment. (H type standard).

Elevating mechanism Headstock elevation accuracy is adjusted by gibs and designed with counterweight balance device to ensure the micro downfeed accuracy.

Double “V” ways for table and saddle Hand-scraped, turcite-B coated longitudinal ways between table and saddle are of double “V” design, ideal for delicate side grinding operations
