SPECIFICITIONS
S. No Specifications SMB 3
1. Drilling Capacity 20
2. No of spindle speeds 8
3. Range of speed 86 to 3326
4. Distance Between Spindle Center & Columm Face 380
5. Max. Distance of spindle to base 940
6. Max. Distance of spindle to work table 495
7. Table Travel 250
8. Spindle Travel 125
9. Table Size 405*405
10. Base Size 650*382
11. Working surface of base 380*470
12. Column Diameter 87
13. Columm Height 1500
14 Spindle Nose Bore MT – 2
15. Motor Recommended 0.75KW (1 H.P.) 1440 RPM
16. V-Belt Size A – 58
17. Weight of Machine(appx) 225 KG
