MODEL NO
MB/14 MB/18 MB/24 MB/30
Maximum Throat capacity 13″ 17″ 23″ 29″
Cutting Capacity 6.5″H x 13″W 8″H x 17″W 12″H x 23″W 15″H x 29″W
Diameter of Saw Wheels
14″ 18″ 24″ 30″
Size of the Tilting
Table – (45) 15″ x 15″
Tilting – (45) 18″ x 18″
Tilting – (45) 24″ x 24″
Tilting – (45) 30″ x 30″
Tilting – (45)
Blade Size for Cutting Wood
0II”,0III”,1W x 111″L 1″,1II”W X135″L 1″,1II”W X174″L 1II”,2″W X210″L
Blade Size for Cutting Metal
0III”,W x 111″L 0III”W x 135″L 0III”W x 174″L 1″W x 210″L
Motor Power Required R.P.M 2 H.P. /3phs.
1440 2 H.P./3phs.
1440 5.H.P / 3phs.
1440 7.5 H.P. / 3phs.
1440
V Belt Size B-51″-1nos. B-54″-1nos. B-68″-2nos. B-84″-3nos.
Machine Size 32″Lx21″Bx64″H 31″Lx25″Bx72″H 48″Lx30″Bx82″H 60″Lx40″Bx98″H
