Brand Sigma
Weight 12.5T,14.5T,16T
Frequency (Hz) 50
Power Supply AC
Phase Three phase
Dimension 9200x3050x1900mm to 11200x3660x1900mm
Voltage 380 V
Travelling Range 3000mmx1500mm,4000mmx2000mm,6000mmx2000mm
Output Power Option 700 W
Laser source IPG fiber laser generator
Beam mode Multimode
Processing surface 3000mm x 1500mm (LxW)
X axle stroke 3050mm
Y axle stroke 1550mm
Z axle stroke 100mm/120mm
CNC system America Delta Tau Systems Inc PMAC full-closed loop servo controller
Total Power consumption 11 kW
Position accuracyX Y and Z axle 0.03mm
Repeatposition accuracyX Y and Z axle 0.02mm
Maximum position speed of X and Y axle 70m/min
Auxiliary gas system Dual-pressure gas route of 3 kinds of gas sources
Format supported AI,BMP,PLT,DXF,DST,etc.
Floor space 5.6m x 3.2m
