Technical Specification
Drilling Capacity 45 MM
Face Milling Capacity 80 MM
End Milling Capacity 32 MM
Tapping Capacity 4 MM to 12 MM
Distance Spindle Axis to Column 260 MM
Spindle Travel 180 MM
Spindle Taper MT 4 and R8
Step of Spindle Speed 6
Range of Spindle Speed 50 Hz 80-1250 RPM
Swivel Angle of Head Stock Verticaly ±90°
Table Size 800 X 240 MM
Forward & Backward Trvel of Table 175 MM
Left & Right Travel Table 500 MM
Motor Power 1.50 KW / 2HP
Net Weight / Gross Weight 370 KG
Packing Size (L x W x H) 770 x 880 x 1160 MM
