Spindle assembly supported in preloaded precession class bearings of P4 Class Accuracy, cartridge cooled. External encoder feedback

Servo spindle and axes drives. Advanced controller

Rigid structured stress relieved bed and slides

Fully supported tool carrier gear box on Y Axis, aligned linear tool slide,6 rotary and 4 linear tools offer many flexible tooling options.

Ball screws and LM ways to all slides

Hydraulic collet chucking

Coolant system and chip tray

Machine Lamp , Panel Lamp, Signal Lamp

Centralized motorized Lubrication System

Totally enclosed machine enclosure with single sliding door, conveniently placed pendant, and ample maintenance accesses

Tool Kit and machine manual

C axis for accurate spindle orientation.
Optional Machine Features :
Chip Conveyor

Auto Loading System

Silent Gravity Bar Feeder

3 Jaw Chuck

Voltage Stabilizer
Abhijat Equipments
